Whittam High Precision Rules (Rulers),
Vernier Scales, C
ircular S
cales,
Index Rings and Machine Dials
custom
made exactly to your specifications!
(especially suitable for industrial applications)
Whittam
High
Precision Calibrated &
Certified
Custom Rulers
made to any length,
Vernier Scales, Circular Scales,
Index Rings and Machine Dials
custom made exactly to your specifications!
(especially suitable for industrial applications)
 Accurately
measure length, radius or circumference with Whittam high quality, high
precision, engraved, metal, metric or inch,
Vertical or Horizontal Rules (Rulers),
X-Ray
Rulers--also called Scanogram/Radiology/Radioopaque Rulers,
Vernier Scales (Verniers),
Index Rings,
Graduated Segments,
Shrink
Rules and Straight Edges,
Circular Divided Scales, and
Machine Dials, etc...
Our
Whittam calibrated engraved rulers plus other Whittam products are of
exceptional quality and precision and boast of a long tradition of
craftsmanship.
Upon
request, our rules (rulers), can be issued an individual Certificate of Calibration
traceable to NIST. Such certificates may be required for companies
qualifying for ISO Certification.
 Made
to any scale length or dial diameter!
Ruler/Vernier Graduations - Inch or metric (or both)!
No minimum quantity required!
Quick delivery--2-3
week delivery is available (std 5-7 wks)
High accuracy in any length or radius--Whittam
rules (rulers/precision scales) are being manufactured with ever increased
accuracy since 1860. Graduated rules can be supplied with accuracies of
1/100 mm (0.0004") over 61 cm (24"). Whittam is capable of manufacturing up
to 132" long scale sections which can be joined together to any length. The
high accuracy is maintained over longer distances by joining the ends ground
for butting within .025 mm (.001"). Our Whittam dials or circular scales are
accurate to within 18 arc seconds or .00045" on a 10" diameter. We offer
circular divided scales and index rings of up to 137 cm (4?") in diameter.
<![CDATA[<a href="https://secure.blueoctane.net//forms/B89RP36J80JI">Click Here To Load This Formexperts.com Form</a>]]>

|
|
Please note:
When asking for a quotation, a simple sketch, like the one below, is
always helpful-
In order to be able to give you an
accurate quote, we need the following information:
a) length
b) width
c) thickness
d) how many edges to be graduated
e) whether inch, metric or both
f) what increments are the graduations to be in
|
 |
Horizontal
Rulers |
 |
Vertical
Rulers |
 |
Vernier
Scales |
/How to read a
vernier |
 |
Shrink
Rulers |
 |
Dials, Rings & Segments |
 |
Circular Divided Scales |
 |
Straight
Edges |
 |
Certificate of Calibration
Unlike our competition, we do not issue Certificates
of Calibration. They are issued by in independent accredited
laboratory regulated by NIST and therefore their accuracy is fully
verifiable. |
Your choice of material, finish and color
(with the exception of wood)--the materials used are generally Hardened and
Tempered Steel, Bright Mild Steel, Stainless Steel, Brass or Aluminum. We
offer matte or polished finishes and a hard chrome plating or electrolyses
nickel plating. Graduations can be left open or filled with one of the basic
colors of your choice (black being the standard).
Guaranteed greater durability in hostile
environment--the engraving (etching
with diamond tip tool) process used by Whittam (versus photo etching) ensures
greater durability of the markings in a hostile environment and the
unmistakable look of quality.
Low prices--up
to hundreds less than our competition! Specializing in custom
designed measurement components gives Whittam a price advantage over
the standard ruler and dial manufacturers who are not set up to
handle "made to measure" orders and may charge you premiums in setup
costs, etc... Our prices can be up to hundreds of dollars less than
our competition--give us a try, call us with your specifications
today!
Made to your exact specifications--all
Whittam
products--horizontal and vertical rules, circular divided scales,
straight and circular vernier scales, straight edges, machine dials
and index rings are made strictly to customer’s specifications with
microscopic attention to detail.
Surpassing Rabone ruler, Lufkin ruler,
Starrett ruler and Shinwa ruler quality
Testimonials
|
|
Past Applications
|
|
Vertical reading scale fitted into the squaring arm of a Cincinnati
Inc. shear
|
|
Multiple engraved sectors and complete dials plus a linear scale on
a Craftsman line-up table
|
|
Horizontal and vertical scales fitted to a DeVlieg "K" jigmil
|
|
Ealing Beck optical bench fitted with scales and verniers
|
|
Vertical dual reading scales and verniers used on a Kearns-Richards
horizontal borer
|
| Dual reading scales fitted to the bed of a Lodge and Shipley lathe
|
|
Whittam index dial on a Setco way slide
|
|
Whittam,
Div. of Schlenker Enterprises,
was founded in 1860 and over the years have established and
maintained an exceptional
reputation for providing high quality precision products to the whole
spectrum of industry all over the United States, Canada and Mexico as well
as in Europe and Australia.
Our Whittam precision scales (rules), verniers and
dials have various uses and are in demand by machine tool and instrument
makers; scientific, meteorological and medical
establishments; graphic art and
photographic companies; as well as the printing; engraving; and automotive
industries. They are known to be called machinist's or engineer's
rules (rulers). In fact, they can be used by anyone who wants to do a good
job accurately.
|
